Effer Truck Cranes
For 50 years now, Effer have been producing the largest range of hydraulic folding truck cranes. Effer hydraulic folding truck cranes with a lifting capacity ranging from 2TM to 300TM are a popular choice on the global market.
Effer achieved something almost impossible, bcombining the lightness of its cranes with the unique power of their performances. Effer are a popular choice for construction, mining and marine industries and boast a power/weight ratio that is the best on the world market. Effer truck cranes are a reliable and safe product, fully compliant to Australian Standards. Effer cranes are all up to date with the newest safety technology available on the market. Some of these features include: radio remote control, overload & operator protection, manual & hydraulic swing up stabiliser legs and much more.
Effer offers the following features:
- Extensions come out in sequence
- High Quality Weldox steel
- One piece boom sections with continuous inner and outer welding
- Use of special materials for the manufacture of extension cylinders
- Decagonal designed second boom structure
- Designed for maximum performance, minimum weight and operational safety
| Model | Max lifting Moment (TM) | Max Outreach (m) | Weight (kg) | Brochure |
|---|---|---|---|---|
| 35 | 2.84 | 7.80 | 535 | Download |
| 65 | 5.74 | 10.70 | 1,010 | Download |
| 80 | 6.71 | 10.93 | 1,135 | Download |
| 100 | 8.45 | 10.77 | 1,315 | Download |
| 135 | 10.31 | 16.82 | 2,105 | Download |
| 150 | 12.79 | 14.65 | 2,115 | Download |
| 175 | 13.88 | 16.72 | 2,305 | Download |
| 215 | 19.31 | 16.91 | 3,030 | Download |
| 255 | 20.19 | 17.11 | 3,445 | Download |
| 265 | 22.87 | 17.10 | 3,445 | Download |
| 305 | 25.04 | 21.41 | 3,925 | Download |
| 315 | 26.69 | 21.42: | 3,945 | Download |
Effer 35 Truck Crane
Effer Cranes
Effer 35 Truck Crane This crane has the longest outreach in its category, which makes it possible to have a perfect coverage of [...]
Effer 65 Truck Crane
Effer Cranes
Effer 65 Truck Crane Small Effer cranes cover the market segment of the lifting classfrom 2 to 10 txm and are a mix [...]
Effer 80 Truck Crane
Effer Cranes
Effer 80 Truck Crane Small Effer cranes cover the market segment of the lifting class from 2 to 10 txm and are a mix [...]
Effer 100 Truck Crane
Effer Cranes
Effer 100 Truck Crane Small Effer cranes cover the market segment of the lifting class from 2 to 10 txm and are a mix [...]
Effer 135 Truck Crane
Effer Cranes
Effer 135 Truck Crane Medium Effer cranes have a lifting capacity between 10 and 30 txm and provide the possibility to create countless configurations according [...]
Effer 150 Truck Crane
Effer Cranes
Effer 150 Truck Crane Medium Effer cranes have a lifting capacity between 10 and 30 txm and provide the possibility to create countless configurations according [...]
Effer 175 Truck Crane
Effer Cranes
Effer 175 Truck Crane Medium Effer cranes have a lifting capacity between 10 and 30 txm and provide the possibility to create countless configurations according [...]
Effer 255 Truck Crane
Effer Cranes
Effer 255 Truck Crane Standard Options: Hexagonal Boom Profile Slew ring & reduction gear unit Boom articulating thru linkrods FPI (Flow proportional power [...]
Effer 265 Truck Crane
Effer Cranes
Effer 265 Truck Crane The 265 crane has the maximum load lifting capacity and an extremely low weight in its category. Apart from ensuring [...]
Effer 305 Truck Crane
Effer Cranes
Effer 305 Truck Crane Effer cranes have a lifting capacity between 10 and 30 txm and provide the possibility to create countless configurations according to [...]
Effer 315 Truck Crane
Effer Cranes
Effer 315 Truck Crane The 315 crane achieves maximum lifting performances for installations on 2-axle trucks, thanks to a design that is careful to all [...]
